APPLICATION ⇒
♦ For symmetric/asymmetric, single/double/triple labeling on the bottleneck
& two sides containers of sundries, chemicals, medicines, foods, wines & oils.
FEATURES ⇒
♦ Main body is universal and angle adjustable according to the shape
& the tilting angle of bottles.
Suitable for most popular bottles in the markets.
♦ Attached with patented adjustable, lifting & fastening mechanism for
precise labeling performance.
Flexible height adjustment and can label up to 3L containers
♦ Labeling:
Two-side symmetric/asymmetric labeling
or three-side asymmetric labeling for square bottles.
♦ Applicable containers:
Oval/round/flat/square bottles.
♦ Materials:
Plastic/glass/metal bottles.
♦ Product specifications:
Machine can be made-to-order.
SPECIFICATION ⇒
| Model | MD-2600 |
| Speed | 10~25 m/min |
| Bottle diameter | Ø25~150 mm |
| Container height | 60~350 mm |
| Label length | 20~300 mm |
| Power | 110/220V, single phase or 220/380v, three phase |
| Main motor power | Step motor |
| Conveyor motor | 1 HP |
| Machine dimension (L x W x H) | 2,400 x 1,700 x 1,700 mm |
