• A smart and user friendly control system is designed in this machine. No special skill or training is required to operate this machine.
• The display on the control panel is simple and clear. With a multifunctional control circuit design, this smart machine can perform five different wrapping modes.
  • Standard wrapping mode.
  • Two different types of single layer wrapping modes.
  • Central area automatic strengthen wrapping mode.
  • Water proof wrapping mode.
• A photoelectric safety switch is equipped to prevent any impact hazard. The machine will automatically halt whenever a hazard occurs, thereby preventing damage to the machine or injury to people.
• A self-detecting system: This machine has an ICON control circuit to monitor the machine's operating status, and self inspection readout facility which enables the operator to visually check all systems. This will also let you identify where there's a breakdown, therefore saving enormous amount of time.
• An advance electronic circuit control includes IP65 circuit, touch screen and water resistant panel box. The use of digital control circuit is three times more stable and reliable than general relays.
• To achieve high safety standards, a highly secure and faulty conducting free concealed conduct rail has been utilized.
• The machine also has a slow starting and stopping device: This device prevents upper packages from falling off during operation. The film carriage speed and revolving speed of the swaying arms can be adjusted allowing speed changes.
• This machine is most suitable for those products that can not be moved before wrapping, and it can be operated without a forklift.

• Pre-Stretch unit: This unit can pre-stretch film up to 300% to save 2/3 times of film cost.
• Conveyor ( for automatic production line ).

Model

SM-2020

SM-2060

SM-2420

Max. packing area

1,300 x 1,300mm

1,400 x 1,400mm

1,500 x 1,500mm

Max. packing height

2,000mm

2,000mm

2,000mm

Rotary arm speed

0-13 / min

0-13 / min

0-13 / min

Film elevator speed

0-3m / min

0-3m / min

0-3m / min

Motor

0.75kW

0.75kW

0.75kW

Max. packing weight

3,000kg

3,000kg

3,000kg
