PRODUCT > STRETCH WRAP MACHINE SM 1506S
Semi Auto Stretch Wrapping Machine - (SM-1506S)
SM-1506S
Semi Auto Stretch Wrapping Machine - (SM-1506S)


FEATURES  ⇒

♦  Full compliance & certified to CE standard.
♦  Adjustable film carriage & turntable speed.

  Use AC Motor, high stability & low maintenance.
♦  Film auto-breaking when wrapping cycle is completed.
  Top & bottom wrapping layers can be set from control panel.
♦  Soft Start & Seop design prevents packages from falling off.
♦  Compact & robust construction with universal turn table design, ensures flexible operation
    in extreme working environment conditions.

SPECIFICATION  ⇒

Model SM-1506S (Super)
Power 230 V, single phase, 50 Hz
Turntable size Ø 1,500 mm
Turntable height 80 mm
Max. packing area 1,300 x 1,300  mm
Max. packing height 2,100 mm
Max. packing weight 1,300 kg
Turntable speed 0-13 rpm
Film elevator speed 0-3 m/min
Motor Turntable 0.37 kW
Motor Film Elevator 0.37 kW
Machine dimension (L x W x H) 2,540 x Ø1,500 x 2,450 mm
